| Technical Parameters of High Precision Turntable | |||||||
| Parameter | Remark | Unit | Groniometer axis | Azimuth axis | Elevation axis | Table axis | Periscopic axis |
| Net flow | — | （deg） （mm） |
±1.35° | contimuous | +10°-90° | -120+380 | ±600 |
| Load | Rated | N | 3000 | 10000 | 10000 | 1500 | 1200 |
| Max. | N | 10000 | 20000 | 20000 | 3000 | 2400 | |
| Torque | Rated | Nm | 1800 | 16600 | 13830 | — | — |
| Max. | Nm | 2400 | 27000 | 16600 | — | — | |
| Load size | Max. | mm | 3500 | ||||
| Load quality | Max. | kg | 120 | ||||
| Reading resolution | — | Count/mm(deg) | 32174.8 | 800 | 800 | 11997.337 | 47995.6 |
| Positioning accuracy | — | mm(deg) | ±0.05° | ±0.03° | ±0.05° | 0.05mm | 0.05mm |
| Motor speed | — | rpm | 3000 | 3000 | 3000 | 3000 | 3000 |
| Working temperature | — | ℃ | -20~80 | ||||
